Trek 2021 E-CALIBER - Dérailleur Hanger

2021 E-Caliber Service Manual
7
Dérailleur hanger
1
2
Item Description Quantity in
Assembly
Part Number Torque (Nm)
1 Thruaxle,M12X1.0X15MM 1 W600321 10
2 Dérailleur hanger 1
W600660
—
Hanger bolt, left-handed thread 1 25
Washer, 25mm 1 —
ThisbicycleframeisdesignedtouseaUniversalDerailleur
Hanger(UDH).
NOTICE: ThethruaxlemustbecompatiblewithaUDH
andmustbeM12x1.0witha12.7mmthread.
NOTICE: Thewasherisframe-specic.Installonlythe
washercompatiblewithyourframe.
WARNING
Donotapplygreasetothederailleurhangerorbolt.Only
applygreasetothethruaxle.
1. Insert the hanger on the inside of the drive-side
chainstay.
2. Installthewasheronthederailleurhangerbolt.
3. Inserttheboltintotheframe.
4. Makesurethehangerispositionedasshownbelow.
5. Torquethehangerboltto25Nm.
NOTICE: Donotover-tighten.Over-tighteningthebolt
couldcausethehangertobreak.
ForadditionalinformationabouttheUDH,refertothe
SRAM user manual at sram.com.
