2021 E-Caliber Service Manual
20
Specications
Chainline (1x only)
52-55 mm
Chainring (1x only)
Minimum 30T
Maximum 32T with 52 mm chain line
36T with 55 mm chain line
Rear brake rotor
Minimum 180 mm direct mount
Maximum 230 mm
Knock Block steering radius
62 degrees
Seat post
Minimum insertion
WARNING
Always follow the seat post manufacturer’s minimum
insertionrecommendation.Failuretofollowtherecom-
mendation could cause damage to the seat post which
couldcausetheridertofallandbecomeinjured.
Maximum insertion
Frame size Maximum
Insertion
Small frame 205 mm
Medium 270 mm
Large
Extralarge
