User manual TREMOL M23
7
memory 8 GB. When the free lines in the EJ buffer are less than 500 free lines, the
opened receipts is closed automatically and ECR allows printing only of daily report and
Fiscal Memory report.
ECR allows reading of the EJ through the PC port by external request.
FUNCTIONAL SPECIFICATIONS
ECR functional registers:
VAT Classes
5
FM Records
Total 2000 for Z-daily reports and special events
Cashiers
Total 20 with programmable name (20 characters) and password
(up to 6 digits)
Pay types
Total 5
1 main CASH (national currency)
3 additional (without exchange rate)
1 currency (with programmable rate towards the main pay type)
Departments
20 with programmable: name (30 characters)
1 (DEP.00) without programming option
Article
Up to 65000 with programmable: name (34 characters), measure
unit, price, price type parameter, VAT Class, Department
attachment, quantity in stock, parameter for quantity watch,
HSCode, HSDesc, single sale and barcode number.
Customers
300 with programmable: VAT Class, name, headquarter, address,
city
INTERFACE SPECIFICATIONS
Electronic scale operation
ECR has possibility to receive quantity from electronic scale. The scale is
connected to the ECR with interface cable. The ECR has 4 set communication protocols
for different scale types. There is option to add 4 more protocols through the interface. The
communication protocol is set in Programming mode, sub mode -LINE-.
External display operation
Instead of a scale on an external display can be connected on the same interface. The
communication protocol is set in Programming mode, sub mode -LINE-.
Barcode scanner operation
ECR operates with barcode scanner RS232 /USB type, allowing fast sales of
articles with barcode label in one of the standards: EAN13, EAN8, UPC-A, UPC-E. The
ECR recognizes automatically the barcode type.
Personal Computer communication
ECR communicates with PC in two main communication modes:
Programming and reporting communication mode is handy when the ECR
operates independent, but is necessary to summarize and store the sale data.
Fiscal printer communication mode for registering sales under PC control.
In this mode the sales are initiated by the PC. ECR keeps its data processing,
accumulated sums in non-volatile memory and stores turnover, VAT sums, counters and
events in fiscal memory.
