PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021 7
Section 1: Overview
The Triga Series TR-FFT Fire Fighter Telephone System provides supervision, annunciation, and control for the local and
remote telephone handsets. The TR-FFT, with keypad, provides indications of phone activation, and corresponding trouble
conditions. Additionally, up to 72 telephone circuits can be annunciated at the TR-FFT by connecting the TR-24Z-EXT zone
expander.
1.1 Features
The TR-FFT features are as follows.
• One Form-C Trouble Relay, System Trouble Relay - TB6
• TR-FFT Fire Fighter Telephone module used for control and annunciation of up to 72 remote telephone jacks
• A maximum of 10 Fire Fighter Remote Handsets (TR-RHS) can be used at one time to communicate over the telephone
circuit connected to the TR-FFT
• Fire Fighter Phone Jack (TR-FPJ) provides a plug-in location for the TR-RHS
• Single Telephone Station (TR-STSR/TR-STSS)
• Fire Fighter Handset Cabinet (TR-HSC) is used to store up to ten Fire Fighter Handsets (TR-RHS)
• System Status LEDs
• Supports two TR-24Z-EXT zone expanders
1.2 Optional Accessories
This Manual contains information on how to install the following compatible accessories with the TR-FFT Series equipment:
1.3 Agency Requirements
The TR-FFT has the same requirements as the main control panel. These requirements are listed in the Triga Series Address-
able FACP Installation Manuals. The FACP Installation Manuals can be found on the web site at www.trigaglobal.com.
1.4 About This Manual
This Manual is intended to be a complete reference for all installation and operation tasks for the TR-FFT. For additional infor-
mation, refer to the following FACP Installation Manuals. The documents are located on the Triga website, www.triga-
global.com.
Model Number Description
TR-24Z-EXT 24 Zone Expander
TR-FPJ Remote Phone Jack
TR-RHS Fire Fighter’s Remote Hand Set
TR-HSC Fire Fighter’s Handset Cabinet
TR-STSR Single Telephone Station Recessed
TR-STSS Single Telephone Station Surface Mount
FFT-BGK Break Glass Kit for TR-STS
TR-MINIMON Addressable Mini-Monitor Module
TR-ISO SLC Line Isolation Module
Table 1.1 Optional Accessories
Document Document Part Number
TR-2100/ECS Manual LS10143-003TR-E
TR-RPS1 Manual LS10259-002TR-E
Triga ECS Manual LS10262-002TR-E
TR-24Z-EXT Product Installation Document LS10305-001TR-E
TR-FPJ Product Installation Document LS10306-001TR-E
TR-HSC Product Installation Document LS10307-001TR-E
TR-STSR/TR-STSS Product Installation Document LS10308-001TR-E
