Trimax SnakeS2 User Manual

TRIMAX SNAKE S2 OPERATORS MANUAL
ENGLISH EDITION
©Trimax Mowing Systems (NZ) Ltd
www.trimaxmowers.com 12 27 March 2019
E. P/N 424-000-030
Label E:
Belt setup. Ensure the Rear Deck belts
are run around the spindles as shown.
F. P/N 424-000-172
Label F:
Belt setup. Ensure the Left-hand Deck
belts are run around the spindles as
shown.
G. P/N 424-000-173
Label G:
Belt setup. Ensure the Right-hand deck
belts are run around the spindles as
shown.
Label positions are shown on the drawings
on the next page.
H. P/N 424-000-137
Label H:
Lifting Points. Use the specified lifting
points whenever lifting the mower.
I. P/N 424-000-031
Label I, left:
Overspeed danger. Parts could fly off if
blades are turning too fast. Ensure the
PTO never runs faster than 540rpm.
PTO rotation direction. Some tractor PTOs
may rotate in the wrong direction. Ensure the
PTO runs in the direction shown by the arrow.
J. P/N 424-101-370
Label J:
Shear hazard. Separate parts of the machine
move in ways that could sever fingers or limbs.
Keep hands and limbs well clear.

Trimax SnakeS2 Specifications

General

Brand	Trimax
Model	SnakeS2
Category	Measuring Instruments
Language	English
