Trimax SnakeS2 User Manual

TRIMAX SNAKE S2 OPERATORS MANUAL
ENGLISH EDITION
©Trimax Mowing Systems (NZ) Ltd
www.trimaxmowers.com 16 27 March 2019
7. Specifications.
GENERAL
MODEL
Snake 320
Snake 400
Cutting width
3234mm (127”)
3994mm (157”)
Overall width
3372mm (133”)
4112mm (162”)
Overall length (drawbar
retracted)
3500mm (138”)
3500mm (138”)
Transport width (standard
road wheels)
2100mm (82 1/2”)
2140mm (84 1/4”)
Transport height
1820mm (71 1/2”)
2215mm (87 1/5”)
Transport length (drawbar
retracted)
3140mm (124”)
3140mm (124”)
Approximate weight
1
1250kg (2756 lb)
1390kg (3064 lb)
Minimum recommended
PTO power
2
26kW (35hp)
33kW (45hp)
Maximum tractor size
56kW (75hp)
56kW (75hp)
Uncut circle diameter
3
Zero turn possible with some tractors
Zero turn possible with some tractors
CHASSIS
MODEL
All Models
Towing hitch
Forged high tensile steel, adjustable
Driveshaft type
1-3/8” x 6-spline couplings both ends, 80 degree constant velocity joint at tractor end
PTO speed
540rpm
Gearbox type
R140
Gearbox ratio
1:1
Gearbox oil
EP90, 1.5 litres
Lift rams
50.8 x 25.4mm (2” x 1”)
Hydraulic system
Hydraulic lift rams operated by tractor auxiliary hydraulic control
Hydraulic connection
1/2” BSP quick-release male probe
Outrigger hinge bearings
High strength reinforced nylon, 63.6mm (2.5”) inside diameter
Transport locks
495mm (19.5”)
Transport lock release
Automatic mechanical hooks
Standard road wheels &
tyres
Rims: steel, 114.3mm (4.5”) PCD x 5 stud pattern
20x10.00-10 6-ply turf tyres
Tyre pressures
210 / 230kPa (30 / 32psi)
Grease points
Outrigger hinges x6
Side deck pitch pivots x4
Lift rams x3
Parking jack x1
Rod ends x2
Primary driveshaft - see instructions
1. Weights are approximate only and depend upon options fitted, see section 9
2. Depends upon tractor and drawbar length
3. Not all options available in some markets
4. Minimum required for trim mowing on level ground Snake 320- 30-37kW (40-50hp)
5. Minimum required for trim mowing on level ground Snake 400- 35-42kW (45-55hp)
