TRIMAX SNAKE S2 OPERATORS MANUAL
ENGLISH EDITION
©Trimax Mowing Systems (NZ) Ltd
www.trimaxmowers.com 17 27 March 2019
MOWER DECKS
MODEL
Snake 320
Snake 400
Cutting width
(left/centre/right)
1160/1160/1160mm (46/46/46”)
1540/1160/1540 (61/46/61”)
Cutting height range
10 – 90mm (3/8” - 3.5”)
Driveshaft type
T40, 1-3/8” x 6-spline couplings
Gearbox type
R240
Gearbox ratio
1:3.1
Gearbox pulley diameter
322mm (12.6”)
No. of blade spindles
(left/centre/right)
3 / 3 / 3
4 / 3 / 4
Spindle pulley diameter
156mm (6.1”)
Idler pulley diameter
105mm (4.2”)
Blade tip diameter
400mm (15.75”)
Blade types (per spindle)
- standard
- options
Trimax LazerBladez
TM
up-turned fling-tip blades
Drive belt type
B-Section back tension
Number of drive belts
3
5
Drive belt tensioning
Cam action flat pulley back idler
Auto belt tensioner
Blade spindle
construction
Maintenance-free, welded steel housing, large diameter high tensile shaft, heavy duty ball
bearings, anti-wrap protection
Idler bearings
Two ball bearings each with double lipped contact seals
Transmission covers
Stainless steel
Transport system
Full width front & rear rollers
Rollers
140mm (5.5”) diameter, ends shaped for scuff protection
Roller bearings
35mm (1-3/8”) heavy duty self-aligning ball bearings, direct greasing
Replaceable LocTek TM Roller Stub Sleeves
Deck Pivot Attachments
- roll axis
- pitch axis, side decks
- roll axis, rear
- pitch axis, rear deck
20mm (0.79”) high tensile bolts, maintenance free composite bushes, nyloil thrust washers
20mm (0.79”) high tensile pins, greaseable steel bush system, nyloil thrust washers
20mm (0.79”) high tensile bolts, maintenance free composite bushes, nyloil thrust washers
16mm (0.63”) high tensile bolts, reinforced nylon bushes, nyloil thrust washers
Grease points (per deck)
Roller bearings x4
Height adjusters x4
Driveshafts - see instructions
Gearbox oil
EP90, 1.5 litres per gearbox
Options*
Anti Wear Skids
Drawbar clevis
Drawbar safety chains
Remote transport lock release
Road kit (mudguards, tail lights, etc.)
Wire roller scrapers
