TRIMAX SNAKE S2 OPERATORS MANUAL
ENGLISH EDITION
©Trimax Mowing Systems (NZ) Ltd
www.trimaxmowers.com 53 27 March 2019
3. Grease outrigger hinge bushes:
a. Lubricate every 150 hours or monthly.
b. Each outrigger (left, rear and right) pivots about a large tubular hinge pin.
c. Grease points are located at either end of the tube (6 in total).
d. Apply 1 shot or 4 pumps of multi-purpose grease to
each point.
4. Grease side deck pitch pivots:
a. Lubricate every 40 hours or weekly.
b. The left and right mower decks each attach to the
outrigger via a hinge that allows it to pitch fore-
and-aft.
c. Grease points are located beneath the outrigger
arm.
d. Apply 1 shot or 4 pumps of multi-purpose grease
to each point (or until grease exits).
