Trio MC403-X User Manual

MC403-X
Document Version: 1.00
© 2023 All rights reserved.
14
MC403-X FEATURE SUMMARY
Dimensions
122 mm x 135 mm x 35 mm (HxWxD).
Weight
346g
Operating Temp.
0 - 45 degrees C.
Control Inputs
Forward Limit, Reverse Limit, Datum Input, Feedhold Input.
Communication Ports
RS232 channel: up to 128k baud. RS485 channel: up to 128k baud. CANbus port
(DeviceNet and CANopen compatible). Ethernet: 100 BaseT multiple port
connection.
Position Resolution
64 bit position count.
Speed Resolution
32 bits. Speed may be changed at any time. Moves may be merged.
Servo Cycle
125µs minimum, 1ms default, 4ms max.
Programming
Multi-tasking TrioBASIC system and IEC 61131-3 programming system. Maximum
6 user processes.
Interpolation modes
Linear 1-3 axes, circular, helical, spherical, CAM Profiles, speed control,
electronic gearboxes.
Memory
8 Mbyte user memory. 512,000 x 64 bit TABLE memory. Automatic flash EPROM
program and data storage.
VR
4096 global VR data in FLASH memory (automatic-store).
SD Card
Standard micro-SD Card compatible to 32Gbytes. Used for storing programs
and/or data.
Power Input
24V d.c., Class 2 transformer or power source required. 18..29V d.c. at 300mA
+ IO supply.
Amplifier Enable Output
Normally open solid-state relay rated 24V ac/dc nominal. Max load 100mA. Max
Voltage 29V.
Analogue Inputs
2 isolated, 12 bit, 0 to 10V.
Serial / Encoder Power Output
5V at 150mA. (Max)
Analogue Outputs
2 isolated 12 bit, +/- 10V
Digital Inputs
8 Opto-isolated 24V inputs.
Digital I/O
4 Opto-isolated 24V outputs. Current sourcing (PNP) 250 mA. (max. 1A per bank
of 4).
Product Codes
P865 : MC403-X 2 axis stepper output / 2 encoder input P866 : MC403-X 1 axis
servo + 2 encoder / 2 axis stepper P867 : MC403-X 2 axis servo + 1 encoder / 3
axis stepper
