Tripp Lite NetCommander B072-016-1-IP User Manual

13
18. Device Upgrade
The B072-016-1-IP has two sets of rmware; one to control IP access
and another to control the KVM’s Mainboard and OSD. This section of the
Web Conguration Interface allows you to update the KVM switches IP
rmware. The non-IP rmware is updated using the KVM OSD. (See Local
FirmwareUpgrade section for details on updating the non-IP rmware)
1. Go to www.tripplite.com/support and nd the available rmware
upgrades for the B072-016-1-IP, and save them on a computer not
connected to the KVM switch.
2. Login to the Web Conguration Interface and click on the Device button.
The current IP rmware version is displayed in the center of the page.
3. Click the Browse button and navigate to and select the le you just
downloaded.
4. Once the new rmware upgrade le is selected, click the Start Upgrade
button. Upon completion, click the Device Reboot button to nish the
upgrade. Depending on the upgrade, the following settings may be
erased: User settings, server names and mouse/videoadjustments.
Networksettings will remain intact.
201204111 93-2769.indd 13 8/2/2012 10:16:00 AM

Tripp Lite NetCommander B072-016-1-IP Specifications

General

Ports quantity	16
Number of users	2 user(s)
Maximum resolution	1920 x 1080 pixels
Certification	UL 60950-1 (USA), CSA (Canada), FCC Part 15 Class A, CE IEC 60950-1
Product color	Black
Rack capacity	1U
Rack mounting	Yes
Cables included	Serial
Number of computers controlled	-
Built-in display	No
Sustainability certificates	RoHS
Package depth	579.1 mm
Package width	256.5 mm
Package height	109.2 mm
Package weight	2990 g
Country of origin	Taiwan
Master (outer) case width	281.9 mm
Master (outer) case height	243.8 mm
Master (outer) case length	591.8 mm
Master (outer) case weight	6760 g
Harmonized System (HS) code	8471.80.1000
Quantity per master (outer) case	2 pc(s)
Master (outer) case GTIN (EAN/UPC)	20037332141600

Weight and Dimensions

Depth	169.7 mm
Width	482.6 mm
Height	43.7 mm
Weight	2130 g
