18
WARNING!
Risk of electrical shock. Consult a qualified electrical and follow
all applicable electrical codes and requirements for hardwire
connections. Disconnect from DC source before attempting
to hardwire. Use wire type THHN or equivalent with minimum
temperature rating of 190°F (88°C).
Battery Connection
PINV3000SWL-120 12V Battery Connection
12V
FUSE
AC Hardwire Output Connection
