Aspirante pumped electric
DO NOT fully tighten the screws at this stage,
as the fixing holes are elongated to allow for
out of square adjustment after the plumbing
connections have been completed.
Note: A temporary factory fitted locking screw
is fitted to the power selector spindle (fig.16).
This is to make sure the spindle is in the Cold
position while the commissioning procedure is
carried out.
DO NOT remove the locking screw before this
procedure is completed.
Fig.11
9
Fig.10

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triton ASPIRANTE Series and is the answer not in the manual?

Triton ASPIRANTE Series Specifications

General IconGeneral
Maximum Static Pressure10 Bar
Water Entry PointsRight Hand Side - Top, Bottom, Back
Cable Entry PointsRight Hand Side - Top, Bottom, Back
TypeElectric
ControlsPush button
FeaturesPush Button Start/Stop
