Triton ASPIRANTE Series User Manual

Start/Stop
button
Temperature
control
Power
selector
Medium
Cold
Full
Low
16
Aspirante pumped electric
OPERATING THE SHOWER
IMPORTANT: Make sure the commissioning
procedure has been carried out.
To start the shower
Pressing the Start/Stop button (fig.35)
switches on the pump, allowing water to
immediately flow through the unit.
To stop the shower
Press the Start/Stop button. This switches off
the pump and the water flow will cease.
To use the power selector
The power selector (fig.35) has four settings –
cold, low, medium and full power.
Blue symbol is cold water only. Adjusting the
temperature control at this setting will only
increase or decrease the force of the water from
the sprayhead. It will not alter the water
temperature.
Red outline symbol is the low setting for extra
economy during warmer months. Temperature
adjustment at this setting is via the temperature
control.
Single red symbol is the medium setting for
economy during warmer months and any
temperature adjustment at this setting is via the
temperature control.
Double red symbol is maximum power setting
which allows the highest flow achievable for
your preferred temperature. Temperature
adjustment at this setting is via the temperature
control.
To adjust the shower temperature
The shower temperature is altered by increasing
or decreasing the flow rate of the water
through the shower via the temperature
control.
After obtaining your preferred shower
temperature, the number can be remembered
as the normal setting and should only need to
be adjusted for seasonal changes in ambient
water temperatures.
Fig.35
WARNING!
If restarting immediately after
stopping, be aware that a slug of
hot water will be expelled for the
first few seconds.

Triton ASPIRANTE Series Specifications

General

Maximum Static Pressure	10 Bar
Water Entry Points	Right Hand Side - Top, Bottom, Back
Cable Entry Points	Right Hand Side - Top, Bottom, Back
Type	Electric
Controls	Push button
Features	Push Button Start/Stop
