MAIN COMPONENTS
Inside unit (fig.1)
1. Top cable entry
2. Bottom pipe entry
3. Rear pipe entry area
4. Rear cable entry area
5. Wall screw fixing
6. Terminal block
7. Power selector
8. Stabilising valve
9. Solenoid valve
10. Guide pockets
11. Can and element assembly
12. Thermal cut-out (main)
13. Earth connection
14. Pressure relief device
15. Outlet temperature limiter
16. Neons
17. Trimplate
Inside cover (fig.2)
18. Cover tags
19. Start/Stop switch
20. Neon bracket
Screw fixing kit
Instructions, guarantee, etc.
Fig.1
Fig.2
NOTE: Not all wiring has been depicted for reasons of clarity
