Triton Omnicare Installation And Operating Instructions

7
SPECIFICATION
ELECTRICAL
Nominal Power Rating at 230V 7.8kW 8.7kW
Nominal Power Rating at 240V
8.5kW 9.5kW
Supply Fuse/Miniature Circuit Breaker
(MCB)
8.5kW - 40Amps
9.5kW - 45Amps
Residual Current Device (RCD) 30mA
Isolation Switch 45Amp Double Pole Isolating Switch, with 3mm
Minimum Contact Gap
Supply Cable Maximum is 16mm, refer to ‘Electrical
Requirements’ section
PLUMBING (See page 10 for plumbing requirements)
Supply Source Mains pressure cold water only
Minimum Dynamic Pressure and flow to the
inlet of the shower
100kPa (1 bar) at 8 litres per minute
50kPa (0.5 Bar) at 8 litres per minute under adnormal
conditions
Maximum Static Pressure 1000 kPa (10 bar)
Maximum inlet temperature 28°C (20°C BEAB Care)
Minimum inlet temperature 2°C (5°C BEAB Care)
Inlet connection ½” BSP male thread for 15mm compression fitting
Outlet connection ½” BSP male thread
MATERIALS
ABS Backplate, cover, controls, showerhead
Minerally insulated corrosion resistant metal
sheathing
Elements
STANDARDS and APPROVALS
Splashproof rating IP25
Safety Complies with the requirements of current British
and European safety standards for household and
similar electrical appliances
BEAB Care Complies with the requirements of the BEAB Care
mark
UKCA/CE Meets with Conformity Assessment for both UK and
EU Markets

Triton Omnicare Specifications

General

Type	Electric Shower
Temperature Control	Thermostatic
Water Connection	15mm compression
Start/Stop Button	Yes
Material	Plastic
Finish	White
Installation Type	Wall Mounted
Warranty	2 years
Water Entry Points	Bottom
Cable Entry Points	Bottom Entry
Approvals	WRAS
