T70Z electric shower
12
Pipe access points on the front cover
The shower cover has been designed with a
removable top trim and 'cut-out' bottom pipe
access points. Fig.8 shows the top access cover
position and the bottom 'cut-out' positions.
If top entry has been chosen, remove the
appropriate pipe cover.
If bottom entry has been chosen, carefully
remove the appropriate 'cut out' using a junior
hacksaw.
Please note: The bottom cut outs are not
designed as 'snap out' entry points to be
removed using pliers. The use of pliers
to remove the cut outs could damage
the cover and may invalidate product
specifications and warranty.
Fig.8
Removable
top pipe
cover
'Cut-out' bottom
pipe access points
