T70Z
electric shower
6
Fig.2
Fig.1
220mm
100mm
300mm
ENTRY POINTS
DIMENSIONS
W
A
TER
Left:
Bottom, Back & T
op.
Right:
Bottom & Back.
CABLE
Left:
Bottom, Back & T
op.
*Right:
Bottom, Back & T
op.
(*
Z uni-fit kit requir
ed.)
= Back
= Back
= Others
= Others
Inlet connection: 15mm diameter
.
Outlet connection: ½” BSP male thread.
5
7
