Triumph Rocket III Handbook

19
General Information
Instrument Panel Layout
1. Reset button
2. ABS warning light
3. Alarm status indicator light (alarm is
an accessory fit)
4. Engine management malfunction
indicator light
5. Low fuel level indicator light
6. High coolant temperature
7. High beam indicator light
8. Neutral indicator light
9. Low oil pressure warning light
10.Turn indicator light
11. Tachometer 'red zone'
12 . R a n g e t o e m p t y
13.Fuel gauge
14.Gear position indicator
15.Tachometer
16.Speedometer
17. Odometer/Trip meter/Clock
cfzs
2 3 4 5 61 87 9
17 16 15 13 11
10
12
14

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
