Triumph Rocket III Handbook

85
Maintenance and Adjustment
Main Fuse Box
ABS Fuse Box
Headlights
Note:
• The vertical beams of the left and
right hand headlights can only be
adjusted together. Independent
adjustment is not possible.
Circuit Protected Rating
(Amps)
Position
Accessory lights 15 1
Ignition switch main feed 30 2
Accessory socket,
instrument memory,
heated grips
10 3
Alarm, diagnostic
connector, indicators,
brake lights, horn
15 4
Instruments, instruments
illumination, fuel pump
relay, starter relay, main
power relay
10 5
Engine management
system relay
20 6
Cooling fan 15 7
Clock, Position lights 5 8
Upper and lower
headlight beams, starter
solenoid
20 9
Position lights 5 10
Main fuse 30 11
Circuit Protected Rating
(Amps)
Position
ABS 20 1
ABS 20 2
Warning
Adjust road speed to suit the visibility and
weather conditions in which the motorcycle
is being operated.
Ensure that the beams are adjusted to
illuminate the road surface sufficiently far
ahead without dazzling oncoming traffic.
An incorrectly adjusted headlight may
impair visibility causing an accident.
Warning
Never attempt to adjust a headlamp beam
when the motorcycle is in motion.
Any attempt to adjust a headlamp beam
when the motorcycle is in motion may
result in loss of control and an accident.

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
