Triumph Rocket III Handbook

88
Maintenance and Adjustment
Rear Light
Bulb Replacement
1. R e a r l i g h t b u l b
2. Bulb holder
Remove the rider’s seat.
Disconnect the battery, negative (black) lead
first.
The rear light bulb holder can be located
underneath the rear mudguard.
Rotate the bulb holder anti-clockwise to
release it from the lamp body.
To remove the bulb from the holder, gently
pull on the bulb until it is released.
Installation for the bulb is the reverse of the
removal procedure.
Indicator Lights
Bulb Replacement
1. Lens
2. Lens screw
3. Bulb
The lens on each indicator light is held in
place by two screws.
Release the screws and remove the lens to
gain access to the bulb for replacement.
Warning
The bulb becomes hot during use. Always
allow sufficient time for the bulb to cool
before handling. Avoid touching the glass
part of the bulb. If the glass is touched or
gets dirty, clean with alcohol before re-use.
Caution
When reconnecting the battery, connect
the positive (red) lead first.

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
