Triumph Rocket III Handbook

22
General Information
Fuel Gauge
1. F u e l g a u g e
2. Range to empty
The fuel gauge indicates the amount of fuel
in the fuel tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel in the tank.
When the fuel tank is full all 16 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
When 3 bars are displayed the low fuel
warning light will illuminate. This indicates
that there are approximately 4.5 litres of fuel
remaining in the tank and you should refuel
at the earliest opportunity.
Note:
• After refuelling, the fuel gauge
and range to empty information
will be updated only while riding
the motorcycle. Depending on the
riding style, updating could take
up to five minutes.
Gear Position Display
1. Gear position symbol
2. Gear position display (neutral
position shown)
The gear position display indicates which
gear (1 to 5) has been engaged. When the
transmission is in neutral (no gear selected),
the display will show 'N'.
1. Gear position display (first gear
shown)
cfzs_3
2
1
.
cfzs_4
2
1
.
cfzs_5
1

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
