Triumph Rocket III User Manual

12
Parts Identification
PARTS IDENTIFICATION
1. Front indicator
2. Headlight
3. Coolant expansion tank
4. Oil filler cap/Dipstick
5. Tool kit (in left hand pannier)
6. Rear light
7. Rear indicator
8. Left hand pannier
9. Side stand
10.Gear change pedal
11. R a d i a t o r
12.Coolant pressure cap
cbnt_1
1 2 3 4 5 6
12 11 10 9 8 7

Triumph Rocket III Specifications

General

Compression Ratio	10.0:1
Final Drive	Shaft
Transmission	5-speed
Rear Brakes	Single 316mm disc, 2-piston caliper
Front Tire	150/80 R17
Rear Tire	240/50 R16
Dry Weight	320 kg (705 lbs)
Fuel System	Electronic fuel injection
Exhaust	3-into-1 into 2
Clutch	Wet, multi-plate
Frame	Tubular steel, twin spine
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Twin 320mm floating discs, 4-piston calipers
Front Wheel	17 x 3.5 in
Fuel Tank Capacity	24 liters (6.3 US gal)
Engine Type	Liquid-cooled, DOHC, in-line 3-cylinder
