Triumph Tiger XRT User Manual

General Information
124
Warning
After adjusting the seat, operate the
motorcycle in an area free from traffic
to gain familiarity with the new seat
position.
Riding the motorcycle with the seat in
an unfamiliar position may cause loss
of motorcycle control and an accident.
4
4
2
5
3
1
chdi_2
1. Rider’s seat
2. Front height adjuster
3. Rear height adjuster
4. Low seat height position (front shown)
5. High seat height position (front shown)
The rider’s seat is adjustable for height
by approximately 0.78 in (20 mm).
To adjust the rider’s seat:
• Remove the rider’s seat (see
page 123).
• Reposition both seat height
adjusters to the higher or lower
position as required. Make sure
that both adjuster rails are fully
engaged in their brackets on the
seat.
• Reinstall the rider’s seat (see
page 123).
Heated Seats (if equipped)
The heated seats switches (if equipped)
are located on the left hand side of the
motorcycle.
1
2
1. Rider’s heated seat switch location
2. Passenger’s heated seat switch
location
The heated seats will only heat when
the engine is running. When the heated
seats are switched on, the heated seats
symbol will appear in the display. The
selected heat level for each seat will
also be indicated by the color of the
symbol.

Triumph Tiger XRT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Transmission	6-speed
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	O-ring chain
Frame	Tubular steel trellis frame
Wheels	Cast aluminium alloy
Power	70 kW
Fuel Capacity	20 L (5.28 US gal)
Wet Weight	221 kg
Rear Suspension	Showa monoshock, adjustable rebound and compression damping
Front Brakes	Twin 305 mm floating discs
Rear Brakes	Single 255 mm disc
Tires (Front)	120/70
Tires (Rear)	170/60 R17
Electronics	Traction control, ABS, Cruise control, Heated grips
