General Information
126
Helmet Hook
Warning
Never ride the motorcycle with
helmet(s) secured to the helmet hook.
Riding the motorcycle with helmet(s)
secured to the helmet hook may cause
the motorcycle to become unstable
leading to loss of motorcycle control
and an accident.
A helmet can be secured to the
motorcycle using the helmet hook
located on the left hand side of the
motorcycle, beneath the rider's seat.
ciuw
1
1. Helmet hook
To attach a helmet to the motorcycle:
• Remove the rider's seat (see
page
123) and loop the helmet chin
strap over the hook.
• To secure the helmet, reinstall the
seat and lock into position (see
page 123).
Tool Kit, Handbook and the
Triumph Accessory D-Lock
The tool kit and handbook are located
beneath the passenger seat.
Space is provided under the passenger
seat to store a Triumph accessory
D-lock (available from your Triumph
dealer).
To secure the lock:
• Remove the passenger seat (see
page 122).
• Release the straps and remove the
handbook and tool kit.
• Position the U-section of the lock
to the rear fender tray support
features, making sure that the
open end faces towards the front
of the motorcycle.
• Position the lock body into the rear
fender tray as shown below.
cjhl
2
1
3
1. Lock U-section
2. Lock body
3. Straps
• Mount the tool kit and handbook
above the D-lock and secure using
the tool kit straps.
• Reinstall the passenger seat (see
page 122).

Triumph Tiger XRT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Transmission	6-speed
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	O-ring chain
Frame	Tubular steel trellis frame
Wheels	Cast aluminium alloy
Power	70 kW
Fuel Capacity	20 L (5.28 US gal)
Wet Weight	221 kg
Rear Suspension	Showa monoshock, adjustable rebound and compression damping
Front Brakes	Twin 305 mm floating discs
Rear Brakes	Single 255 mm disc
Tires (Front)	120/70
Tires (Rear)	170/60 R17
Electronics	Traction control, ABS, Cruise control, Heated grips
