Triumph Tiger XRT User Manual

How to Ride the Motorcycle
140
Stopping the Engine
Tiger 1200 XR Only
P
U
S
H
P
O
F
F
O
N
RES /+
SET /-
ON
3
4
21
1. Neutral indicator light
2. OFF position
3. Ignition switch
4. Engine stop switch - STOP position
To stop the engine:
• Close the throttle completely.
• Select neutral.
• Turn the ignition switch off.
• Select first gear.
• Support the motorcycle on a firm,
level surface with the side or center
stand.
• Lock the steering.
Caution
The engine should normally be stopped
by turning the ignition switch to the
OFF position.
The engine stop switch is for
emergency use only.
Do not leave the ignition switched on
with the engine stopped. This will
cause electrical damage.

Triumph Tiger XRT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Transmission	6-speed
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	O-ring chain
Frame	Tubular steel trellis frame
Wheels	Cast aluminium alloy
Power	70 kW
Fuel Capacity	20 L (5.28 US gal)
Wet Weight	221 kg
Rear Suspension	Showa monoshock, adjustable rebound and compression damping
Front Brakes	Twin 305 mm floating discs
Rear Brakes	Single 255 mm disc
Tires (Front)	120/70
Tires (Rear)	170/60 R17
Electronics	Traction control, ABS, Cruise control, Heated grips
