16
PARTS IDENTIFICATION
1
2
3 456
9
10
20
19
18
17 16 15 13 12 11
8
14
7
1. Headlight
2. Front turn signal
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Rider’s heated seat switch
(Tiger 1200 XR only)
6. Battery and fuse boxes (under the seat)
7.
Passenger’s heated seat switch
(if equipped)
8. USB socket (under the seat)
9. Electrical accessory socket
(if equipped)
10.
Rear turn signal
11. Rear brake caliper
12. Rear brake disc
13. Center stand (if equipped)
14. Rear suspension damping adjuster
(Tiger 1200 XR only)
15. Side stand
16.
Gear shift pedal
17. Coolant expansion tank
18. Radiator cowl
19. Front brake caliper
20. Front brake disc
