Instruments
21
INSTRUMENTS
Instrument Displays
Overview
There are two types of instrument
displays mounted to specific
motorcycles models.
All Models except Tiger 1200 XR
All models except for Tiger 1200 XR are
equipped with a full color Thin Film
Transistor (TFT) digital instrument
display.
ODOMETER
0
MILES
Thin Film Transistor (TFT) Instrument
Display
For more information on the TFT
instrument display and its operation,
see page 22.
Tiger 1200 XR Models Only
Only Tiger 1200 XR models are equipped
with a Liquid Crystal Display (LCD)
instrument display.
Liquid Crystal Display (LCD) Instrument
Display
For more information on the LCD
instrument display and its operation,
see page 57.

Triumph Tiger XRT Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Transmission	6-speed
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	O-ring chain
Frame	Tubular steel trellis frame
Wheels	Cast aluminium alloy
Power	70 kW
Fuel Capacity	20 L (5.28 US gal)
Wet Weight	221 kg
Rear Suspension	Showa monoshock, adjustable rebound and compression damping
Front Brakes	Twin 305 mm floating discs
Rear Brakes	Single 255 mm disc
Tires (Front)	120/70
Tires (Rear)	170/60 R17
Electronics	Traction control, ABS, Cruise control, Heated grips
