T R O G E S AIRSET – Montage-, Betriebs- und Wartungsanleitung
AIRSET – Assembly, Operation and Maintenance Instructions
- 37 -
Component-No
element-No
activity-No
activities interval
components and
elements
period
on demand
1 Air discharge device
1 1 Fans
1 1 1 Check pollution, damaging,
corrosion and fastenings. M
1 1 2 Cleaning for save function
X
1 1 3 Check unbalancing of wheel M
1 1 4 Check function of the blade
adjust device Y
1 1 5 Check noise of bearings M
1 1 6 Grease all regreasable
bearings H
1 1 7 Check tightness of flexible
canvas Q
1 1 8 Check function of anti
vibration dampers H
1 1 9 Check function of safety
devices M
1 1 10 Check function of vane
control Y
1 1 11 Check function of drainage H
1 1 12 Check hygienic condition M
1 1 13 Drive units see pos 10
1 1 14 ICA -devices see VDMA 24186 part 4
2 Heat exchangers
2 1 Air heater (air/fluid)
2 1 1 Check airside pollution,
damaging and corrosion Q
2 1 2 Cleaning for save function
X
2 1 3 Check function of flow and
return H
2 1 4 Ventilate Y
2 1 5 Check hygienic condition M
2 2 Electric heater
2 2 1 Check scale formation and
corrosion M
2 2 2 Cleaning for save function
X
2 2 3 Check function H
2 2 4 Check ICA and safety devices
M
2 2 5 Check hygienic condition M
2 3 Air cooler (air/fluid)
2 3 1 Check airside pollution,
damaging and corrosion Q
2 3 2 Cleaning for save function
X
2 3 3 Check function of flow and
return H
2 3 4 Ventilate Y
2 3 5 Check function of drain and
siphon Q
2 3 6 Drop eliminator see pos. 4.2
2 3 7 Check hygienic condition M
2 4 Evaporator (air/refrigerant)
2 4 1 Check airside pollution,
damaging, corrosion and icing
Q
2 4 2 Cleaning for save function
X
2 4 3 Check icing Q
2 4 4 Check function of drain and
siphon
2 4 5 Drop eliminator see pos. 4.2
2 4 6 Check hygienic condition M
2 5 Rotary heat exchanger
2 5 1 Check airside pollution,
damaging and corrosion M
2 5 2 Cleaning for save function
X
2 5 3 Check unbalancing of wheel Y
2 5 4 Check noise of bearings M
Component-No
element-No
activity-No
activities interval
components and
elements
period
on demand
2 5 5 Grease all regreasable
bearings Y
2 5 6 Check function of sealing
elements (sight check) Y
2 5 7 Check hygienic condition M
2 5 8 Drive units see pos 10
2 6 Plate heat exchanger
2 6 1 Check airside pollution,
damaging and corrosion Q
2 6 2 Cleaning for save function
X
2 6 3 Check function of cleaning
device H
2 6 4 Check function of drain and
siphon Q
2 6 5 Check hygienic condition M
3 Air filter
3 1 Roll band filter
3 1 1 Check pollution, damaging
and corrosion M
3 1 2 Cleaning for save function
X
3 1 3 Detect pressure drop M
3 1 4 Check function of filter feed
rate Q
3 1 5 Check function of ICA device Q
3 1 6 Refill measuring solution
X
3 1 7 Check reserve of filter
medium M
3 1 8 Change filter band
X
3 1 9 Check hygienic condition M
3 1 10 Drive units see pos 10
3 2 Dry layer filter
3 2 1 Check pollution, damaging
and corrosion M
3 2 2 Cleaning for save function
X
3 2 3 Detect pressure drop M
3 2 4 Check tightness of filter frame H
3 2 5 Clean filter medium if
regenerative
X
3 2 6 Change filter medium and
keep records
X
3 2 7 Check hygienic condition M
3 3 Electric filter
3 3 1 Check pollution, damaging
and corrosion M
3 3 2 Cleaning for save function
X
3 3 3 Check damaging of
ionisations wires H
3 3 4 Change ionisation wires
X
3 3 5 Check filter cells against
damaging and sparking M
3 3 6 Check tight seat of insulators Q
3 3 7 Change insulators
X
3 3 8 Detect current consumption H
3 3 9 Check function of cleaning
device H
3 3 10 Check hygienic condition M
3 3 11 Drive units see pos 10
3 3 12 ICA -devices see VDMA 24186 part 4
3 4 Sorption filter
3 4 1 Check physical pollution,
damaging and corrosion H
3 4 2 Cleaning for save function
X
3 4 3 Check tight seat of filter insert H
3 4 4 Change filter insert
X
3 4 5 Check hygienic condition M
