T R O G E S AIRSET – Montage-, Betriebs- und Wartungsanleitung
AIRSET – Assembly, Operation and Maintenance Instructions
- 38 -
Component-No
element-No
activity-No
activities interval
components and
elements
period
on demand
3 5 Filter for suspended matter
(Global activities can not be
appointed. They are
depending on the particular
conditions of installation and
operation)
4 Humidifier
4 1 Air washer and honeycomb
4 1 1 Check pollution, incrustation,
damaging and corrosion Q
4 1 2 Cleaning for save function
X
4 1 3 Check function of water
supply and distribution M
4 1 4 Check water level M
4 1 5 Adjust regulation device for
water level
X
4 1 6 Check function of sludge
device Q
4 1 7 Adjust sludge device
X
4 1 8 Check function of drain and
overflow M
4 1 9 Check pollution of strainer M
4 1 10 Clean strainer
X
4 1 11 Check function of pump M
4 1 12 Detect bacterial count H
4 1 13 Check hygienic condition M
4 2 Drop eliminator / Flow straightener
4 2 1 Check pollution, incrustation,
damaging and corrosion Q
4 2 2 Cleaning for save function
X
4 2 3 Check function of drain and
siphon Q
4 2 4 Check hygienic condition M
4 3 Steam humidifier with steam generator
4 3 1 Check pollution, damaging
and corrosion Q
4 3 2 Cleaning for save function
X
4 3 3 Check function of water
supply and water level Q
4 3 4 Check pollution of strainer Q
4 3 5 Clean strainer
X
4 3 6 Check function of magnet
valve M
4 3 7 Check function of ICA and
safety device M
4 3 8 Check steam cylinder for
scaling M
4 3 9 Change or regenerate steam
cylinder
X
4 3 10 Check function of steam
distributor and nozzles Q
4 3 11 Check damage and tightness
of steam and condensate
hose H
4 3 12 Check for condensate
formation
4 3 13 Check hygienic condition M
4 4 Steam humidifier without steam generator
4 4 1 Check pollution, damaging
and corrosion Q
4 4 2 Cleaning for save function
X
4 4 3 Check pollution of strainer Q
4 4 4 Clean strainer
X
Component-No
element-No
activity-No
activities interval
components and
elements
period
on demand
4 4 5 Check function of regulation
valve Q
4 4 6 Check function of steam
distributor and condensate
line H
4 4 7 Check for condensate
formation
4 4 8 Check hygienic condition M
4 4 9 ICA -devices see VDMA 24186 part 4
4 5 Ultrasonic- Spray- and. Hybrid humidifier
4 5 1 Check pollution, incrustation,
damaging and corrosion Q
4 5 2 Cleaning for save function
X
4 5 3 Clean water tank M
4 5 4 Check function of electrical
system Q
4 5 5 Check function of energy
converter (only for ultrasonic
humidifier) Q
4 5 6 Change energy converter
(only for ultrasonic humidifier)
X
4 5 7 Check function of water
supply and distribution M
4 5 8 Check function of pump Q
4 5 9 Check hygienic condition M
5 Elements of the air distribution system
5 1 Weather lovers
5 1 1 Check pollution, damaging
and corrosion H
5 1 2 Cleaning for save function
X
5 2 Dampers
5 2 1 Check pollution, damaging
and corrosion H
5 2 2 Cleaning for save function
X
5 2 3 Check mechanical function H
5 2 4 Grease bearings and
connecting rods
X
5 2 5 Damper actuator see VDMA 20186 part 4
5 3 Chambers
5 3 1 Check pollution, damaging
and corrosion Y
5 3 2 Cleaning for save function
X
5 3 3 Check function of drain Y
5 3 4 Clean drain
X
5 3 5 Check tightness and free
movement of doors and
hinges Y
5 3 6 Check thermal insulation for
damaging Y
5 3 7 Check tightness of flexible
canvas Y
5 5 8 Clean chambers inside
X
5 5 9 Check hygienic condition M
5 4 Fire dampers and valves
5 4 1 Check catching device for
function and damaging Y
5 4 2 Check tripping device for
function and pollution Y
5 4 3 Check sealing for damaging
and pollution Y
5 4 4 Cleaning for save function
X
5 4 5 Change tripping element
X
5 4 6 Check free movement Y
5 4 7 Check function of position
indicator Y
