T R O G E S AIRSET – Montage-, Betriebs- und Wartungsanleitung
AIRSET – Assembly, Operation and Maintenance Instructions
- 39 -
Component-No element-No activity-No
activities interval
components and
elements
period on demand
5 4 8 Damper actuator see VDMA 20186 part 4
5 5 Ducts
5 5 1 Check all accessible ducts
including the thermal
insulation for physical
damaging and corrosion (sight
check) Y
5 5 2 Check function of drain Y
5 5 3 Clean drain X
5 5 4 Check tightness of accessible
flexible canvas (sight check) Y
5 5 5 Random check of accessible
ducts for internal pollution and
check hygienic condition M
5 6 Grille
5 6 1 Check textile grille for physical
damaging and pollution (sight
check) Y
5 7 Silencer
5 7 1 Check pollution, damaging
and corrosion Y
5 8 Mixing-/Relaxation camper and air flow
regulator
5 8 1 Check pollution, damaging
and corrosion Y
5 8 2 Cleaning for save function X
5 8 3 Check function of damper Y
5 8 4 Damper actuator see VDMA 20186 part 4
5 9 Isolation- and adjustment element
5 9 1 Check pollution, damaging
and corrosion Y
5 9 2 Cleaning for save function X
5 9 3 Check function Y
5 9 4 Damper actuator see VDMA 20186 part 4
9 Control box, ICA- devices and building
automatisation system see VDMA 22186 part 4
10 Drive units
10 1 Electric motor
10 1 1 Check pollution, tight seat,
damaging and corrosion M
10 1 2 Cleaning for save function X
10 1 3 Check rotation direction M
10 1 4 Fasten connection terminal X
10 1 5 Detect voltage Q
Component-No element-No activity-No
activities interval
components and
elements
period period
10 1 6 Check tight seat of connection
terminal H
10 1 7 Detect current consumption Q
10 1 8 Check rotation direction of
three phase current. Q
10 1 9 Check smooth running and
temperature M
10 1 10 Check noise of bearings M
10 1 11 Grease all regreasable
bearings H
10 1 12 Check function of safety
devices M
10 2 Belt drive
10 2 1 Check pollution, damaging
and abrasion M
10 2 2 Cleaning for save function X
10 2 2 Check tension and alignment M
10 2 3 Adjust belt drive X
10 2 4 Change V-belt X
10 2 5 Check function of safety
devices M
10 3 Drive coupling
10 3 1 Check pollution, tight seat,
damaging and corrosion M
10 3 2 Cleaning for save function X
10 2 3 Check alignment Q
10 3 4 Check temperature Q
10 3 5 Change oil X
10 3 6 Check function of safety
devices M
10 4 Gear
10 4 1 Check pollution, damaging
and corrosion M
10 4 2 Check tight seat and noice M
10 4 3 Cleaning for save function X
10 4 4 Check alignment Q
10 5 5 Change oil H
11 Documentation and Labelling
11 1 Service interval documents (e.g. plan,
manufacturer rules)
11 1 1 Check existence M
11 2 Existing unit marking (signs, color code, rating
plate, approval ID)
11 2 1 Check existence M
