HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Basic tools, such as spanners will be required for assembly.
No. Description Qty
57 Cross Head Screw ST4.2 x 13 mm 8 pcs
44 Cup Head Hex Screw M8 x 50 mm 4 pcs
55 Lock Nut M8 4 pcs
45 Cup Head Hex Screw M6 x 16 mm 8 pcs
51 Flat Washer Ø8 mm 4 pcs
52 Saddle washer Ø8 mm 12 pcs
Spanner 1 pcs
Hex Key 5 mm 1 pcs
Hex Key 6 mm 1 pcs
Hardware Kit B01154500
ST4, 2 x 13 mm Cross
Head Screw (57) 8 pcs
M8 x 16 mm Cup Head
Hex Screw (45) 8 pcs
M8 x 50 mm Cup Head
Hex Screw (44) 4 pcs
Spanner 1 pcs
6 mm Hex Key 1 pcs
Ø8 Flat Washer-C
(51) 12 pcs
Ø8 Saddle Washer
(52) 4 pcs
M8 Non-Metal Hex
Nut (55) 4 pcs
5 mm Hex Key 1 pcs
