Trojan Iginte 370 - Parts List

29
10334
PARTS LIST
No. Description Specication Qty
1 Base Bottom Bracket 1
2 Frame 1
3 Left Upright Bar 1
4 Right Upright Bar 1
5 Console 1
6 Spring Fixed Set
40 mm x
Ø32 mm
1
7 Incline Bracket 1
8 Upper Adjustable Tube 1
9 Filter Fixed Plate 2
10 Motor Bracket 1
11 Motor Cover 1
12 Motor Lower Cover 584 mm x 375 mm x T1.6 mm 1
13 Front Roller
Ø100 mm x Ø48 mm x 553 mm
1
14 Back Roller
Ø46 mm x 558 mm
1
15 Running Deck 1082 mm x 605 mm x T18 mm 1
16 Running Belt 2555 mm x 450 mm x T1.6 mm 1
17 Side Rail 81 mm x 40.4 mm x 992 mm 2
18 Foam Cover 2
19 Left End Cap 145 mm x 97.5 mm x 103.8 mm 1
20 Right End Cap 145 mm x 97.5 mm x 103.8 mm 1
21 Adjust Pad
Ø44.2 mm x 35 mm
4
22 Spring
Ø22 mm x 810mm x 200 N
1
