PARTS LIST
No. Description Specication Qty
23 Moving Wheel
Ø60 mm x 25 mm
4
24 Spring Clip 1
25 Running Deck Cushion 45 mm x 33 mm x T3.0 mm 2
26 Side Rail Fixed Button
Ø20 mm x 6.8 mm
8
27 Square Tube 50 mm x 25 mm x 1.5 mm 2
28 Circle Tube 38 mm x T1.5 mm 2
29 V-Belt 210 mm (7 tooth x 6 groove) 1
30 Incline Motor JS15 x 200 mm x 70 mm, Voltage 220V 1
31 Motor 1.25 HP, Voltage 180 V 1
32 Power Bracket 1
33 Motor Shock Plate 1 100 mm x 65 mm x T3.0 mm 1
34 Console 769.7 mm x 396.5 mm x 85 mm 1
35 Console Lower Cover 762.7 mm x 385 x T1.6 mm 1
36 Console Display Board 351 mm x 223.1 x 37.8 mm 1
37 Safety Key
Ø34 mm x 10 mm
1
38 Music Speaker 3W, 8Ω 2
39 Cross Head Screw ST3.5 x 13 mm 1
40 Console Sticker 1
41 Tie 4 mm x 150 mm 5
42 Bolt Plastic
Ø25 mm x Ø10.5 mm x T2.0 mm
2
43 Rubber Cushion
35 mm x
Ø20 mm
4
44 Cup Head Hex Screw M8 x 50 mm x 15 mm 4
