Trojan Iginte 370 - Page 31

31
10334
PARTS LIST
No. Descriptoon Specication Qty
45 Cup Head Hex Screw
M8 x
Ø16 mm
4
46 Hex Screw M10 x 28 mm 4
47 Cup Head Hex Screw
M8 x 45 mm x
Ø20 mm
3
48 Cup Head Hex Screw M8 x 40 mm x 15 mm 2
49 Hex Screw M8 x 80 mm 2
50 Cup Head Hex Screw M8 x 35 mm 1
51 Flat Washer-C
Ø8 mm
35
52 Saddle Washer
Ø8 mm
4
53 Rocker Switch 250V AC/8A 1
54 Flat Washer-C
Ø10 mm
10
55 Non-Metal Hex Nut M8 mm 18
56 Non-Metal Hex Nut M10 mm 4
57 Cross Head Screw ST4.2 x 13 mm 43
58 Cup Head Hex Screw M8 x 55 mm 1
59 Cross Head Screw M8 x 25 mm 6
60 Cross Head Screw M8 x 35 mm 2
61 Cross Head Screw ST4.2 x 13 mm 14
62 Philips Shantou Self-Drilling Screw ST4.2 x 13 mm 26
63 Bolt Screw M8 x 12 mm 2
64 Bolt Screw M8 x 16 mm 4
65 Cross Head Screw M4 x 8 mm 13
66 Screw M10 x 50 mm x 20 mm 1
