PARTS LIST
No. Description Specication Qty
67 Screw M10 x 65 mm x 20 mm 1
68 Cross Head Screw ST4.2 x 38 mm 12
69 Cross Head Screw ST4.2 x 20 mm 4
70 Cross Head Screw ST4.2 x 9.5 mm 8
71 Cross Head Screw ST3 x 8 mm 21
72 Heart Rate Fixed Button 4
73 Inductance (Optional) T5817-1 ACL-2.5 mH-6 A 1
74 Motor Controller AC220 V with incline B304S 1
74 Motor Controller AC110 V with incline B304S 1
75 Filter (Optional) 10 A 120/250 V-50/60 HZ 1
76 Side Rail Rear Connector 81 mm x 40.4 mm x 2.2 mm 1
77 Spring Cushion
Ø30 mm x 20 mm, M8, 15-17 mm
6
78 Motor Shock Plate 2 155 mm x 100 mm x T3.0 mm 1
79 Screw M8 x 35 mm 1
80 Safety Key Bracket 1
81 Power Cord
Voltage 220 V,
Ø1.0 M x 2000 mm
1
82 Left Hand Pulse Set 1
83 Right Hand Pulse Set 1
84 Computer Connect Wire 700 mm x 10 PIN 1
85 Base Frame Connect Wire 1800 mm x 10 PIN 1
86 Cup Head Hex Screw M8 x 12 mm 4
87 Music Board 400 mm 1
88 Main Control Board 1
