Trojan IGNITE 360 - Page 16

16
10292
PARTSLIST
NO. Factory P/N ENGLISH NAME SPECIFICATION. Qty
28 3280005 Speed Sensor Wire 2P x 1100 mm 1
29 4243007 Binder 3
30 3210070 Console Master Wire 4P x 900 mm 1
31 3210023 Base Connect Wire 4P x 1900 mm 1
32 3210071 Speaker Cable 2P x 700 mm 2
33 3210025 Speaker Cable 2P x 270 mm 2
34 4020006 Left Roller End Cap 126.8 mm x 99.8 mm x 91 mm 1
35 4020005 Right Roller End Cap 126.8 mm x 99.8 mm x 91 mm 1
36 5300012 Platform Cushion T3.0 x 45 mm x 33 mm 4
37 4180001 Roller Wheel Ø60 x 25 mm 4
38 4080006 Tube Cover 30 mm x 60 mm x 1.5 2
39 4990001 Guide Of Side Rail Ø19 x 6.8 mm 6
40 5200002 Rubber Cushion Nut Ø30 x 28 mm x M8 / 15-17 mm 4
41 4990011 Plastic Washer T2.0 x Ø20 x Ø10.5 2
42 4080009 Tube Cover T1.5 x 30 mm x 30 mm 2
43 4100001 Bottom Left Cover 495.6 mm x 65 mm x 179.2 mm 1
44 4110001 Bottom Right Cover 495.6 mm x 65 mm x 179.2 mm 1
45 5250009 Foot Bumper M10 / 15 mm x 15 mm 4
46 4080021 Tube Cover XG-107 – T2.0 x 40 mm x 80 mm 2
47 4990010 Moving Part Ø13 x 50 mm x 39.5 mm 2
48 5300004 Motor Cushion 1 T3.0 x 100 mm x 65 mm 1
49 5300003 Motor Cushion 2 T3.0 x 155 mm x 100 mm 1
50 8000002 Running Board T18 x 1240 mm x 547 mm 1
51 2600002 Front Roller Ø56 x 553 mm 1
52 2610002 Rear Roller Ø46 x 555 mm 1
53 5000002 Running Belt T1.8 x 2825 mm x 450 mm 1
54 2620002 Air Shock Ø22 2
55 5100002 V Belt 210 mm 1
56 3750001 Magnetic Ring Ø31 x Ø19 x 13 mm 1
57 3250801 Power Cord 1
58 3020002 Incline Motor 1
59 3000008 Main Motor 1
