Trojan PURSUIT 310 - Parts List

10102M-13
9. PARTS LIST
No. Description Q’ty
42 Bearing <6000ZZ.> 1
43 Bearing <6003ZZ> 2
44 Bearing <6300ZZ> 1
45 38mm Washer 1
46 Ball Bearing Ring Nut (R) 1
47 Bearing Bowl 2
48 Ball Bearing Ring Nut (L) 1
49 35mm Washer 1
50 Ring Nut 2
51 Ball Bearing 2
52 Clip C10 1
53 Spring (Small) 1
54 Spring (Big) 1
55 Wheel Assy 2
56 Front Foot Cover 2
57 Rear Foot Cover 2
58 M8 Nylock Nut 3
59 Clamp Cover 1
60 T Knob 1
61 Quick Release Knob 1
62 M8 Washer 3
63 Saddle Support Tube Insert 1
64 Drive Belt Wheel 1
65 M8*72mm Allen Head 2
66 Pedal (L/R) 1
67 Seat 1
68 Foam Grip 2
69
70
End Cap of Handlebar
Belt
2
1
71 Chain Cover (L) 1
72 Chain Cover (R) 1
73 Crank Cover 2
74 Washer Curve M5 1
75 Tension Control 1
76 Tension Connector 1
77 Computer 1
78 Computer Wire 1
79 Sensor Wire 1
80 Hand Pulse Wire 1
81 Sensor Bracket 1
82 Hand Pulse Grips 2
No. Description Q’ty
1 Base Frame 1
2 Handlebar Post 1
3 Handlebar 1
4 Saddle Post 1
5 M5”12mm Screw 4
6 Magnet 1
7 Front Stabilizer 1
8 Rear Stabilizer 1
9 Magnetic Holder 1
10 Bracket 1
11 Bush 1
12 Crank 1
13 Belt Wheel 1
14 Flywheel 1
15 Flywheel Axle 1
16 Front Pulley 1
17 Bearing IC1735-FT 1
18 M8*78mm Allen Head 2
19 M10*35mm Allen Head 1
20 M8*15mm Allen Head 4
21 M8*52mm Hex Head Bolt 1
22 M8*25mm Hex Head Bolt 1
23 Screw #10 *24 *5/8 1
24 M4*16mm Screw 2
25 M5*10mm Screw 1
26 Screw #8-32 *5/8 4
27 M30*0.8mm Washer 1
28 M10*2.0mm Washer 1
29 M8*1.5mm Waher 1
30 M8*1.2mm Washer 9
31 M8 Spring Washer 7
32 M10 Nylont Washer 2
33 3/8" Nut (t=9mm) 1
34 3/8" Nut (t=3mm) 1
35 M8 Cap Nut 2
36 M10 Nut (t=6mm) 1
37 Nylock Nut M8 2
38 3/8” WH Nut 2
39 Tool - Spanner 1
40 Tool - Spanner 1
41 Tool - Allen Key 1
