3. HARDWARE LIST
11460-5
3. HARDWARE LIST
NOTE :
The described parts are all you need to assemble this machine.
Before starting assembly, please check the hardware packing to make sure they are included.
No. Description Q’ty
6
Domed Nut (M8)
4pcs
5
Arc Washer (ø8 x ø20 x T1.5)
8pcs
4
Bolt (M8 x 70mm)
4pcs
14
15
13
Screw Driver
1pc
No. Description Q’ty
24
Screw (M8 x 12mm)
4pcs
18
Adjustment Knob (M12)
1pc
33
T Knob
1pc
M8
6
Allen Wrench
1pc
