8
PARTS LIST
No. Description Qty
A Bolt (M8 x 45 mm) 4
B Washer (Ø8.4 x Ø16 x 1.5T) 14
C Bolt (M8 x 16 mm) 6
D Hex Head Bolt (M8 x 15 mm) 2
E Washer (Ø8.2 x Ø32 x 2.0T) 2
F Nut (M10) 2
G Washer (Ø10.2 x Ø32 x 2.0T) 2
H Hex Head Bolt (M8 x 75 mm) 2
I Nut (M8) 10
J Screw (M4 x 20 mm) 6
K Screw (M3 x 15 mm) 6
L Hex Head Bolt (M8 x 45 mm) 4
M Bolt (M8 x 43 mm) 4
N Arc Washer (Ø8.5 x Ø20 mm) 4
O Arc Washer (Ø8.5 x Ø20 x R30 mm) 2
P Spring Washer (Ø8.2 mm) 4
Q Bolt (M8 x 25 mm) 2
R Screw (M4 x 12 mm) 2
S Washer (Ø19.4 x Ø24 mm) 4
T Screw (M4 x 25 mm) 1
U Wrench (S6) 1
V Wrench (S17-19) 1
W Wrench (S13-14-15) 1
X Wrench (S13-14) 1
Y Washer (ID4) 2
Z Wrench (S5) 1
1 Main Frame 1
2 Front Stabiliser 1
3 Rear Stabiliser 1
No. Description Qty
4 Front Post 1
5 The Middle Handlebar 1
6 Console 2
7 R, L Lower Handlebar (R, L) 2
8 R, L Upper Handlebar (R, L) 2
9 R, L Pedal Arm (R, L) 2
10 R, L Pedal (R, L) 2
11 R1, R2 End Cap 2
11 L1, L2 End Cap 2
12 Steel Bushing 8
13 Plastic Spacer 2
14 End Cap 2
15 Washer 4
16 Screw 4
17 a, b Tension Knob and Cable 1 set
18 RR, RL End Cap 2
18 LR, LL End Cap 2
19 Steel Bushing 4
20 R, L End Cap 2
21 Plastic Spacer 2
22 R1, R2 Handlebar Cover (right) 2
22 L1, L2 Handlebar Cover (left) 2
23 Sponge Tube 2
24 End Cap 2
25.1, 25.2 Handlebar Cover (middle) 2
26 Sponge Tube 2
27 End Cap 2
28 a, b, c Console Wire 1 set
29 Front Post Cover 1
