Trojan WALKER 110 - Page 19

10200-19
No. Description Qty
52 Motor Adjustment Plate NAZ409185 1
53
54 Outer Cap PAD30 2
55 CKSHexScrewM8xP1.25x105(15mm) 1
56 CKSHexScrewM8xP1.25x15 2
57 CKSHexScrewM8xP1.25x45 4
58
59 Rubber Pad 3
60 EndCapmatchwith□25x50x1.5t 2
61 Lower Motor Cover 1
62 Washer Drilling Philips Self Tapping Screw
Ø4x12
10
63 Base Assembly 1
64 TrussHexScrewM8xP1.25x35 2
65 ArcWasher-OuterSpan20x8.5x1.5t(R19.05) 2
66 Foot Pad PCFP1155 6
67 WasherØ6xØ16x1.0t 6
68 Washer Drilling Philips Self Tapping Screw
-Ø4x20
6
69 Wheel PCZ21-ZTXA 2
70 TrussHexScrewM8xP1.25x50(12mm) 2
71 NylonNutM8xP1.25 9
72 TrussHexScrewM8xP1.25x52 2
73 TrussHexScrew1/2”-20UNFx80(30mm) 2
74 Safety Key 1
75 HexSpanner+PhilipsScrewdriver
5mm(70mmx70mm)
1
76 Wire Clip Knob UC-1 1
77 Round Head Drilling Philips Self Tapping Screw
Ø4x16
2
No. Description Qty
78 TrussHexScrewM8xP1.25x15 4
79 EndCapRoundTube30x1.2t 2
80 NylonNutM6xP1.0 4
81 ExtensionWire
16AWGx250,(FBG16AWG250WH)
1
83 Nut M8 4
84 Plastic Bottle Seat 1
85 Wheel PBKHM068 2
86 PlasticWasherØ8xØ22x6t 2
87 Spannersize13 1
88
89 FixingPlasticPEZP319 2
90 RoundHeadPhilipsScrewM6xP1.0x42 4
91 WasherØ19xØ6x1.5 4
92 ExtensionWire(Kelly)14AWGx150mmx1T1R 1
93 Filter 1
94 TrussPhilipsScrewM5xP0.8x10 2
95 Aluminum Control Board 1
96
97 L-shaped Plastic PDD54540 1
98 Washer Drilling Philips Self Tapping Screw
Ø4x12
3
99 Spring 1
100 RoundHeadPhilipsScrewM4xP0.7x8 2
101 TrussPhilipsScrewM5xP0.8x18 2
102 SILICON 1
103
104 Choke 1
105 TrussPhilipsScrewM4xP0.7x10 2
13. PARTS LIST (cont.)
