Trojan WALKER 110 - Maintenance Procedures; Applying Treadbelt Lubricant; Belt Tracking Adjustment

10200-9
HOW TO APPLY LUBRICANT
• Liftonesideoftreadbelt.
• Pouronehalfofthelubricantbottleunderthecentreofthetreadbeltonthetopsurfaceofthetreadboard.
• Walkonthetreadmillataslowspeedfor3to5minutestoevenlydistributelubricant.
 NOTE:DONOToverlubricatetreadboard.Anyexcesslubricantthatcomesoutshouldbewipedoff.
NOTE: ONLY USE HALF THE BOTTLE OF LUBRICANT PER APPLICATION.
LUBRICATION SCHEDULE.
• Checkthetreadboardlubricationduringinstallation.Ifit’snecessary,lubricatethetreadboard,usingonehalfofthe
lubricant provided, before using the treadmill for the rst time.
• Ifthetreadmillisusedonaregularbasis,therunningdeckshouldbelubricatedonceamonth.
• Ifthetreadmillisnotusedfortwomonthsormore,thetreadmillmustbelubricatedbeforeuse.
6. MAINTENANCE
HOW TO CHECK TREADBELT FOR PROPER
LUBRICATION
•Liftonesideofthetreadbeltandfeelthetopsurfaceofthe
treadboard.
•Ifthesurfaceisslicktothetouch,thennofurtherlubricationis
required.
•Ifthesurfaceisdrytothetouch,applyonepacketoflubricant
or half of the bottle of lubricant.
BELT TRACKING ADJUSTMENT
• Ifduringuseyounoticethattherunningbelteithershiftstotherightortheleftofcentre,switchoffthetreadmill,
remove the “Safety Key” and unplug the equipment from the AC power source.
• Iftherunningbeltshiftsleft,usingM6AllenKeyprovided,turn
 theleftrearrolleradjustmentclockwisenomorethe1/4”ofaturn
(if the running belt shifts right, adjust the right rear roller).
• RemovetheM6AllenKey,insertthe“SafetyKey”andinsertthe 
AC power cord into the AC outlet. Turn on your treadmill and
observe after running for a few minutes to see if the problem
has been corrected.
• Thismaytakeseveraladjustments,sorepeattheaboveprocedure.
Your treadmill should require little maintenance other than to periodically apply lubricant. Lubricating under the
treadbeltwillensuresuperiorperformanceandextendthetreadmill’slifeexpectancy.
