Trojan WALKER 110 - Parts List

10200-18
13. PARTS LIST
No. Description Qty
1 Computer Console 1
2 Computer Handrail Tube Assembly 1
3 Hand Pulse Set NAZNO2531&FBOP1136 2
4 FoamGripØ36x2.5tx280(FAE2536280) 2
4A FoamGripInnerSpanØ34x2.5tx560 2
5 Hand Pulse Screw Cover 2
6 Hand Pulse Sensor Wire(Lower） 2
7 TrussPhilipsSelfTappingScrewØ3.5x16 4
8 --- --
9 SocketPhilipsSelfTappingScrewØ4x25 2
10 POP-Pin Head 1
11 Spring 1
12 Pin 1
13 Upright(Left) 1
14 Upright(Right) 1
15 Control Wire 1
16 Upper Motor Cover 1
17 Running Belt 1
18 Pedal 2
19 Double Sided Tape 4
20 Running Board 1
21 SocketPhilipsScrewM6xP1.0x45 6
22 CounterSinkHexScrewM8xP1.25x30 2
23 Frame Assembly 1
24 Rubber Pad PECP1434 6
25 Front Roller 1
No. Description Qty
26 SocketPhilipsScrewM6xP1.0x25 1
27 Rear Roller 1
28 Rear End Cap(Left) 1
29 Rear End Cap(Right) 1
30 WasherØ6xØ10x1.0t 2
31 CKSHexScrewM6xP1.0x55(FullThread) 2
32 Incline Base 1
33 TrussPhilipsScrewM5xP0.8x10 5
34 Controller 1
35 WasherPhilipsSelfTappingScrewØ4x16 4
36 Power Cord Clip 1
37 CircuitBreaker 1
38 Power Switch 1
39 ExtensionWire
16AWGx90mm,(FBG16AWG90WH)
1
40 ExtensionWire16AWGx250,(FBG16AWG250) 1
41 Power Cord 1
42 Sensor 1
43 Wire Clip Knob UC-0.5 1
44 Wire Clip Knob UC-0 2
45 Washer Drilling Philips Self Tapping Screw
Ø4x16
4
46 CKSHexScrewM8xP1.25x80(40mm) 1
47 Spring Washer M8 3
48 WasherØ16xØ8x1.5t 1
49 Nut M8 1
50 Motor Set 1
51 Drive Belt 1
