Trotec Speedy 360 Guide

- 24 -
Laser cutting does not start even after the data loaded
to Trotec JobControl is output.
Is the line color of the cut data in Adobe
Illustrator one of the colors in the Trotec
color swatch (FCLaser_
****
)?
Select the line color for the cut data from one
of the 16 colors in the Trotec color swatch.
( P.16 "Select the line color for the cut
data from the Trotec color swatch.")
Are the correct laser cutting conditions set
for the line color of the cut data in the Tro-
tec JobControl material template?
In the Trotec JobControl [Material database]
dialog, please set the cut data line color [Pro-
cess] to [Cut], and set the correct laser cut-
ting conditions.
Is the [No response from engraver...] mes-
sage displayed?
Please contact Trotec Laser GmbH.
Is the LaserCut PC connected to the Tro-
tec Speedy Laser Engravers via a USB
cable?
Connect them using a USB cable.
Is the Trotec Speedy Laser Engravers
power turned on?
Turn on the power to the Trotec Speedy
Laser Engravers.
In [View devices and printers] on the Con-
trol Panel, is the [USB-Serial Converter?]
device operating correctly?
(If this is not operating correctly, an excla-
mation mark is displayed on the [USB-
Serial Converter?] icon.)
Insert the Trotec JobControl CD in the PC
and update the device.
Be sure to perform this update while the Tro-
tec Speedy Laser Engravers (powered on) is
connected.
Please contact Trotec Laser GmbH.
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes
No
Yes

Trotec Speedy 360 Specifications

General

Max. Speed	3.55 m/s
Laser Type	CO2 Laser
Software	JobControl
Resolution	1, 000 dpi
Positioning Accuracy	0.1 mm
Repeatability	± 0.01 mm
Power Supply	110 - 240 V, 50/60 Hz
Weight	220 kg
Laser Power	10 - 120 watts
