- 26 -
Using the laser cutter without printing
This section covers the case where the [Quick Print] check box is checked on the Trotec UniDrive [UniDrive
(Manual Mode)] dialog. ( P.12 "Check or uncheck the [Quick Print] check box.")
1. Create a cut layer using Adobe Illustrator
Uncheck the [Print] check box.
2. Create the cut data.
3. Select the line color for the cut data from
the Trotec color swatch.
4. Set the media on the Trotec Speedy
Laser Engravers.
Set it so that it is aligned with the upper left cor-
ner of the laser cutter surface.
5. Adjust the height.
For more details, please refer to the Trotec
Speedy Laser Engraver operation manual.
6. Click the [Output to TrotecLaser] button
on the FineCut menu.
