Trotec TGP 1005 E - Technical Annex

12 EN
garden pump TGP 1005 E
Technical annex
Technical data
Parameter Value
Model TGP 1005 E
Max. flow rate 3300l/h
Max. delivery head 42m
Max. suction height 7m
Max. air pressure 4.2bar
Max. water temperature 35°C
Thermal overload protection 150°C
Power supply 230V ~ 50Hz
Power input 1000W
Protection type of the pump IPX4
Protection type of the mains plug IP44
Connection type CEE 7/7
Cable length 1.2m
Protection class I
Weight 6.5kg
Dimensions
(lengthx widthx height)
200x 400x
210mm
Max. particle size 2mm
Pressure connection 1" internal thread
Suction connection 1" internal thread
Sound values according to EN ISO 3744:1995
Sound pressure level L
pA
72dB(A)
Sound power level L
WA
88dB(A)
Uncertainty K
WA
2dB(A)
Circuit diagram TGP1005E
