Trotec TGP 1005 E - Page 14

14 EN
garden pump TGP 1005 E
No. Part Name Quantity No. Part Name Quantity
1 Filter cover
1
27 Motor Rear Cover
1
2 O Ring
1
28 Outer Hex Bolt
4
3 Filter
1
29 Fan Blade
1
4 Filter holder
1
30 Circlip (Ø 12)
1
5 Dustproof Cap
2
31 Handle Cover
1
6 Seal Bolt 1/2"
1
32 Handle + fan cover
1
7 O ring
1
33 Philips Screw
2
8 End cap
1
34 Inner hexagon Screw
2
9 Inner hexagon Screw
8
35 Spring Washer
1
10 Pump housing
1
36 Flat gasket 6*12*1.0 S
1
11 Flat Gasket
8
37 Support Foot
1
12 O ring
1
38 Terminal Box Holder
1
13 Plastic Retaining Ring
1
39 Philips Screw
4
14 Diffuser
1
40 Square Gasket
1
15 O ring
1
41 Self-tapping Screw
2
16 Impeller
1
42 Power Cord Clip
1
17 Mechanical seal (MG13)
1
43 Power Cable Jacket
1
18 Flange Plate
1
44 Terminal Box Cover
1
19 Thrower 12
1
45 Triangular groove screw
4
20 Aluminum Holder
1
46 Square Gasket
1
21 Bearing
1
47 Waterproof Switch
1
22 Rotor
1
48 Switch Cover
1
23 Bearing
1
49 Outer Frame of Switch
1
24 Stator
1
50 Capacitor
1
25 Motor housing (105)
1
51 Capacitor Holder
1
26 Corrugated Gasket
1
52 Power Cable
1
