Trox Technik AURASAFE mini TX-CTRL Series - Appendix A: Modbus Memory Map

33
NO/DK/GB
CMD 4 - read input registers
Reg adr
30001:0
30001:1
---
30001:14
30001:15
30002:0
30002:1
---
30016:14
30016:15
30017:0
30017:1
---
30017:14
30017:15
30018:0
30018:1
---
30032:14
30032:15
30033:0
30033:1
30033:2
30033:3
30033:4
30033:5
30033:6
30033:7
30033:8
30033:9
30033:10
30033:11
30033:12
30033:13
Type
Input state
Input state
---
Input state
Input state
Input state
Input state
---
Input state
Input state
Tx present
Tx present
---
Tx present
Tx present
Tx present
Tx present
---
Tx present
Tx present
System ready
Test in progress
System running
Dampers open
Damper ON fail
Damper OFF fail
Smoke alarm
---
EXT IN alarm
SEF alarm
Interlock ON
---
---
Alarm
Bus adr
i1
i2
---
i15
i16
i17
i18
---
i255
i256
i1
i2
---
i15
i16
i17
i18
---
i255
i256
CMD 5 - write coils
Bit adr
257
258
259
---
262
263
264
Type
Reset alarm
Damper test
Interlock
---
Bus adr. 124
Bus adr. 125
Bus adr. 126
Comment
To reset the alarm switch bit 257 ON and then OFF
To perform system test switch bit 0 ON and then OFF
1: Interlock activated
---
Set output address on bus (Relay output module etc.)
Set output address on bus (Relay output module etc.)
Set output address on bus (Relay output module etc.)
CMD 16 – write output registers
Reg adr
40017:0
40017:1
40017:2
40017:3
40017:4
40017:5
40017:6
40017:7
Type
Reset alarm
Damper test
Interlock
--
--
Bus output adr. 124
Bus output adr. 125
Bus output adr. 126
Comment
To reset the alarm switch bit 0 ON and then OFF
To perform system test switch bit 0 ON and then OFF
1: Interlock activated
Not used
Not used
Set output address on bus (Relay output module etc.)
Set output address on bus (Relay output module etc.)
Set output address on bus (Relay output module etc.)
APPENDIX A: Modbus
memory map
