TX-RKS
Bit Value Description
Input-1
0 Damper NOT closed
(S1 and S2 NOT connected)
1 Damper closed
(S1 and S2 connected)
Input-2
0 Damper NOT open
(S4 and S6 NOT connected)
1 Damper open
(S4 and S6 connected)
Output-1
0 Close damper
1 Open damper
Output-2
0 Not used
1 Not used
TX-BRS
Bit Value Description
Input-1
0 Damper NOT closed
(S1 and S2 NOT connected)
1 Damper closed
(S1 and S2 connected)
Input-2
0 Damper NOT open
(S4 and S6 NOT connected)
1 Damper open
(S4 and S6 connected)
Output-1
0 Close damper
1 Open damper
Output-2
0 Not used
1 Not used
TX-RBRS
Bit Value Description
Input-1
0 Damper NOT closed
(S1 and S2 NOT connected)
1 Damper closed
(S1 and S2 connected)
Input-2
0 Damper NOT open
(S4 and S6 NOT connected)
1 Damper open
(S4 and S6 connected)
Output-1
0 Close damper
1 Open damper
Output-2
0 Not used
1 Not used
TX-TEM3
Bit Value Description
Input-1
0 Fire detected (PT1000 removed, or
over limit)
1 OK
Input-2
0 OK
1 Fire detected (PT1000 removed, or
over limit)
Output-1
0 Running normally
1 Inverts inputs
Output-2
0 Not used
1 Not used
TX-FEP
Bit Value Description
Input-1
0 Button NOT pressed
1 Button pressed
Input-2
0 Not used
1 Not used
Output-1
0 Alarm + LED disabled
1 Alarm + LED activated
Output-2
0 Not used
1 Not used
Object description of every module, continued
