ID5000, XR5000 Level 1 Service Manual
Issue 4, 8/2017 11
Parts list
The spare parts differ, depending on the when the indicator was manufactured. Make sure that you have checked
the serial number on the indicator before ordering any spare parts.
Description Contents Quantity per unit Part number
LCD Models with serial number >510,000
(includes sticky rectangular gasket).
1 831705P
Models with serial number <510,000
Replace the entire product with a new
indicator. See
Changes to product on
page 7.
Not available
LCD FPC Models with serial number >510,000
(includes connector).
1 831706P
Models with serial number <510,000 1 823360P
LCD connector clips Models with serial number >510,000
(Kit of 10 clips).
2 832344P
LCD black rubber gasket Black rubber gasket.
Models with serial number <510,000
1 823346P
Battery Models with serial number >510,000
(Kit of 2 batteries).
1 831940P
Models with serial number <510,000
(Kit of 2 batteries).
1 825662P
PCA (printed circuit assembly) XR5000
ID5000
1
1
832663P
831943P
Keypad FPC 1 824573P
Case front assembly XR5000 with serial number >510,000
ID5000 with serial number >510,000
(sticky rectangular gasket fitted, without
LCD)
1
1
832718P
832664P
XR5000 with serial number <510,000
ID5000 with serial number <510,000
(with window and screen protector)
1
1
827836
827835
Case rear (includes vent) 1 827837
O-ring One o-ring is required per indicator. 1 823287P
Cradle Models with serial number >510,000 1 831945P
Models with serial number <510,000 1 823345P
USB connectors assembly (Includes FPC) 1 827831
C16 male load bar connector
assembly
(1 connector supplied, includes FPC) 2 827832
C16 female power/comms
connector assembly
(1 connector supplied, includes FPC) 1 827833
Screw kit case (Kit of 50 screws used for securing the case
components).
12 816752P
