True ALPINE RUNNER - Page 19

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 19 of 50
ASSEMBLY STEPS:
Step 11 Console Assembly:
Step 12 Rear Console Cover:
a) Attach the rear console cover using 3
screws as shown.
Hardware Required:
1 M4xP0.7x12mm Screws
2 M4xP0.7x80 Screws
Place the two bottom console mounting screws
inside the bottom keyholes on the console mast
assembly. Partially thread the two top console
mounting screws into the console. Fully tighten all
four console mounting screws.
Note: Ensure all cable connections are routed
inside the console mast assembly to prevent cable
pinching.
Note: Refer to the respective console manual
included with your console for wiring connections.
Hardware Required:
Part Number 00567800
Qty 4: M5 x 12 bolts
